Our architectural monolithic glass can be produced in a range of thicknesses from 30mm – 100mm. fbloc captures the unique optical and tactile qualities of glass with an outstanding range of thick monolithic panels, offering exciting architectural and structural possibilities.

fbloc is manufactured as a clear low iron optical glass (slight green tint) but can also be produced with blue or grey body tints. The thickness of the glass dictates the depth of the colour and transparency of the panel.

fbloc is only available as an annealed glass but the monolithic nature of the glass means that it is extremely strong with minimal chance of breakage from everyday use. As with all annealed glass, however, the edges are more vulnerable to chipping if impacted with a hard object.

As with all kiln formed glass, one face remains smooth whilst the other face is textured. The standard texture is a stippled effect although the glass can be manufactured to bespoke textures if requested. Non-slip textures can also be added to the surface if required.

Slide background
Slide background

SPECIFICATION:

Available in annealed glass only.



MAX. PANEL SIZE & WEIGHT:

Slab size of fbloc is dependant on the site’s weight limitations and is usually manufactured to a maximum weight of 250kg.



THICKNESS:

50mm – 130mm as standard. Other thicknesses available on request.



WEIGHT:

30mm thick = 75kg/m2
40mm thick = 100kg/m2
50mm thick = 125kg/m2
60mm thick = 150kg/m2
70mm thick = 175kg/m2
80mm thick = 200kg/m2
90mm thick = 225kg/m2
100mm thick = 250kg/m2
110mm thick = 275kg/m2
120mm thick = 300kg/m2



GLASS OPTIONS:

Standard Float Glass (slight green tint)
Low Iron (crystal clear)
Body Tinted (transparent coloured)
Mirror Backed



EDGE OPTIONS:

Polished all round (PAR)
Arrised all round (AAR)
Ground all round (GAR)



SURFACE FINISHES:

Sandblast (etch) to front and/or rear face of glass.



APPLIED FINISHES

Opaque colours, transparent colours or mirror finish can be applied to the rear of the glass.



PROCESSING OPTIONS:

Due to the thickness of fbloc there are limitations to drilled holes, cut-outs and shaping the glass. Please speak to our Sales Team for more information.



TOLERANCES:

+/- 3mm (glass size)
